تفاصيل المنتج:
شروط الدفع والشحن:
|
| نموذج المحرك: | 3066 3046 | نموذج الآلة: | 311ب 311ج 312 312ب 315ب 318ج 320ب |
|---|---|---|---|
| تطبيق: | شاحنة ، مجموعة مولد | اسم المنتج: | مستشعر درجة حرارة الماء |
| رقم الجزء: | 5I-7578 5I7578 | التعبئة: | كرتونة التصدير القياسية |
| إبراز: | Excavator water temperature sensor,311B 312B temperature sensor,318C excavator electric parts,311B 312B temperature sensor,318C excavator electric parts |
||
| Name | Water Temperature Sensor |
| Parts No | 5I-7578 5I7578 |
| Machine Model | 311 311B 311C 312 312B 315 315B 315C 317B LN 318B 318C 320B |
| Category | Electric Parts, Water Lines |
| Lead time | 1-3 DAYS |
| Quality | Brand new, OEM quality |
| MOQ | 1 PCS |
| Means of transport | By sea/air, DHL FEDEX UPS TNT EMS |
| Packing | As request or standard packing |
| 1.Senses coolant temperature in the engine cooling system. |
| 2.Converts temperature into an electrical signal (typically a variable resistance output). |
| 3.Transmits data to the ECU, which uses it to: |
| Adjust fuel injection timing |
| Control the cooling fan |
| Trigger warning lights/alerts for overheating |
| Optimize overall engine performance and emissions |
EXCAVATOR 311 311B 311C 312 312B 315 315B 315C 317B LN 318B 318C 320 L 320B 320B L 320C 320C FM 320N 321B
| 2746721 SENSOR GP-PRESSURE |
| 3054E, 3056E, 311D LRR, 312D, 312D L, 313D, 314D CR, 314D LCR, 315C, 315D L, 318D L, 319D, 319D L, 319D LN, 320D, 320D FM, 320D FM RR, 320D GC, 320D L, 320D LN, 320D LRR, 320D RR, 321D LCR, 323D L, 32... |
| 1918304 SENSOR GP-SPEED |
| 120K, 120K 2, 120M, 120M 2, 12K, 12M, 12M 2, 12M 3, 12M 3 AWD, 140K, 140K 2, 140M, 140M 2, 140M 3, 140M 3 AWD, 14M, 160K, 160M, 160M 2, 160M 3, 160M 3 AWD, 16M, 420E, 420F, 428E, 428F, 430E, 430F, 432... |
| 2380112 SENSOR GP-TEMPERATURE |
| 120M, 120M 2, 12M, 12M 2, 12M 3, 12M 3 AWD, 140M, 140M 2, 140M 3, 140M 3 AWD, 14M, 160M, 160M 2, 160M 3, 160M 3 AWD, 16M, 226B, 232B, 236B, 236B3, 242B, 242B3, 246C, 247B, 252B3, 256C, 257B, 257B3, 25... |
| 3203060 SENSOR-PRESSURE |
| 120M 2, 12M 2, 12M 3, 12M 3 AWD, 140M 2, 140M 3, 140M 3 AWD, 160M 2, 160M 3, 160M 3 AWD, 2384C, 2484C, 2570C, 2670C, 2864C, 312D2, 312D2 GC, 312D2 L, 312E, 312E L, 313D2, 313D2 LGP, 314E CR, 314E LCR,... |
| 3203061 SENSOR-PRESSURE |
| 120M 2, 12M 2, 12M 3, 12M 3 AWD, 140M 2, 140M 3, 140M 3 AWD, 160M 2, 160M 3, 160M 3 AWD, 2384C, 2484C, 2570C, 2670C, 2864C, 312E, 312E L, 314E CR, 314E LCR, 316E L, 318E L, 320E, 320E L, 320E LN, 320E... |
| 3203062 SENSOR GP-PRESSURE |
| 120M 2, 12M 2, 12M 3, 12M 3 AWD, 140M 2, 140M 3, 140M 3 AWD, 160M 2, 160M 3, 160M 3 AWD, 2384C, 2484C, 2570C, 2670C, 2864C, 312E, 312E L, 314E CR, 314E LCR, 316E L, 318E L, 320E, 320E L, 320E LN, 320E... |
| 3203063 SENSOR GP-PRESSURE |
| 120M 2, 12M 2, 12M 3, 12M 3 AWD, 140M 2, 140M 3, 140M 3 AWD, 160M 2, 160M 3, 160M 3 AWD, 2384C, 2484C, 2570C, 2670C, 2864C, 312D2, 312D2 GC, 312D2 L, 312E, 312E L, 313D2, 313D2 LGP, 314E CR, 314E LCR,... |
| 1166680 SENSOR AS-SPEED |
| 3054, 3056, 554, 793F, 793F AC, 793F CMD, 793F OEM, 793F-XQ, 795F AC, 795F XQ, 797, 797B, 797F, 914G, 924G, 924GZ, AP-650B, AP-800D, BG-225C, C175-16, C175-20, C3.3, C4.4, C6.6, C7.1, CB-434D |
| Pos. | Part No | Qty | Parts name | Comments |
| 1 | 8T-6912 M | [3] | BOLT (M8X1.25X50-MM) | |
| 2 | 5I-7578 | [1] | SENDER-TEMPERATURE (WATER) | |
| 3 | 5I-7572 | [1] | GASKET | |
| 4 | 5I-7735 | [1] | GASKET | |
| 5 | 5I-8010 | [1] | REGULATOR-TEMPERATURE (COOLANT) | |
| 6 | 5I-8056 | [2] | PLUG | |
| 7 | 3B-4505 | [17] | LOCKWASHER | |
| 8 | 2M-5446 | [6] | GASKET | |
| 9 | 5I-7977 | [1] | PIPE | |
| 10 | 125-2981 | [1] | COVER AS | |
| 11 | 5I-7655 | [1] | PIPE | |
| 12 | 5I-7646 | [1] | ELBOW | |
| 13 | 2S-3440 | [2] | CLAMP-HOSE | |
| 14 | 5I-7699 | [1] | HOSE | |
| 15 | 095-1663 | [1] | SEAL-O-RING | |
| 16 | 8T-4908 M | [13] | BOLT (M8X1.25X25-MM) | |
| 17 | 096-9532 | [2] | WASHER (15.8X22.5X2-MM THK) | |
| 18 | 8T-4177 M | [1] | BOLT (M8X1.25X90-MM) | |
| 19 | 135-2336 | [1] | SENSOR-TEMPERATURE (WATER TEMPERATURE) | |
| M | METRIC PART |
1 Hydraulic parts: hydraulic pump, main valve, hydraulic cylinder, final drive, travel motor, swing machinery, swing motor etc.
2 Engine parts: engine ass’y, piston, piston ring, cylinder block, cylinder head, crankshaft, turbocharger, fuel injection pump, starting motor and alternator etc.
3 Undercarriage part: Track roller, Carrier roller, Track Link, Track shoe, Sprocket, Idler and Idler cushion etc.
4 Cab parts: operator’s cab, wiring harness, monitor, controller, seat, door etc.
5 Cooling parts: Radiator, air conditioner, compressor, after cooler etc.
6 Other parts: Service kit, swing circle, engine hood, swing joint, fuel tank, filter, boom, arm, bucket etc.
Advantage
1. Offer Top quality & competitive products
2. Support 12-month warranty
3. 100% tested before shipping
4. Delivery in time
5. A wide range of Oil Pressure Sensor, Fuel Tank Level Sensor, Temperature Sensor, Speed Sensor for excavator
6. More than 15 years production and 11 years foreign trade experience
7. Professional QC team
8. Best sales team, 24 hours service
Packing Details :
inner packing : plastic film for wrapping
external packing : wooden
Shipping :
within 3 days after received the payment , by air or by express or by sea on the basis of the
quantity and emergency circumstances.
1. By Couriers: DHL, UPS, FEDEX, TNT are the main courier companies we are cooperated,
2. By Air: Delivery from the Guangzhou air port to customer's destination city air port.
3. By Sea: Delivery from the Huangpu port .
